THIS 45° ELBOW FITTING FEATURES JAPANESE METRIC FEMALE THREADS WITH A 60° INTERNAL CONE METAL-TO-METAL SEAL, MANUFACTURED AS A SINGLE-PIECE FORGED STRUCTURE.
| PART NO. | THREAD E | HOSE BORE | DIMENSIONS | |||||
|---|---|---|---|---|---|---|---|---|
| BRAIDED | SPIRAL | DN | DASH | A | C | S1 | S2 | |
| 28611-14-04RW | -- | M14X1.5 | 6 | 04 | 20.5 | 10.5 | 19 | 19 |
| 28611-14-06RW | -- | M14X1.5 | 10 | 06 | 20 | 10.5 | 19 | 19 |
| 28611-16-04RW | -- | M16X1.5 | 6 | 04 | 23.5 | 10 | 22 | 22 |
| 28611-16-05RW | -- | M16X1.5 | 8 | 05 | 23.5 | 10 | 22 | 22 |
| 28611-16-06RW | -- | M16X1.5 | 10 | 06 | 23 | 10 | 22 | 22 |
| 28611-18-06RW | -- | M18X1.5 | 10 | 06 | 24 | 11.5 | 24 | 24 |
| 28611-18-08RW | 28612-18-08RW | M18X1.5 | 12 | 08 | 25 | 11.5 | 24 | 24 |
| 28611-20-08RW | 28612-20-08RW | M20X1.5 | 12 | 08 | 27.5 | 12 | 27 | 27 |
| 28611-22-08RW | 28612-22-08RW | M22X1.5 | 12 | 08 | 27.5 | 14 | 27 | 27 |
| 28611-24-08RW | 28612-24-08RW | M24X1.5 | 12 | 08 | 29 | 15 | 32 | 32 |
| 28611-24-10RW | 28612-24-10RW | M24X1.5 | 16 | 10 | 29.5 | 15 | 32 | 32 |
| 28611-30-12RW | 28612-30-12RW | M30X1.5 | 20 | 12 | 29.5 | 18.3 | 36 | 36 |
| 28611-33-12RW | 28612-33-12RW | M33X1.5 | 20 | 12 | 31.5 | 21.3 | 41 | 41 |
| 28611-33-16RW | 28612-33-16RW | M33X1.5 | 25 | 16 | 34.7 | 21.3 | 41 | 41 |
| 28611-36-20RW | 28612-36-20RW | M36X1.5 | 32 | 20 | 34.7 | 20 | 46 | 46 |
| 28611-42-24WRW | 28612-42-24WRW | M42X1.5 | 40 | 24 | 42 | 18.8 | 55 | 55 |
Selection note: JAPANESE METRIC FEMALE THREAD 60° INTERNAL CONE SEAT. Verify thread size, sealing form and pressure rating against the equipment port before ordering. Common sizes are available from stock, and custom production to drawing or sample is available with material and plating options.
