The Vibration Isolation Hose is a flexible connecting hose installed between vibrating equipment and fixed piping systems. It isolates and absorbs vibration and noise generated by machinery (such as compressors, water pumps, and engines), while compensating for displacement caused by thermal expansion/contraction and installation misalignment. Featuring a corrugated flexible structure and multi-layer reinforcement, the hose delivers excellent vibration isolation, pressure resistance, and flexibility—effectively extending the service life of equipment and piping systems. It is widely used in HVAC, refrigeration systems, industrial pump sets, and marine power applications.
| ITEM CODE | I.D mm | WALL THICKNESS WT (mm) | MAX LENGTH m |
| NRF102 | 102 | 4 ~ 6 | 5 |
| NRF127 | 127 | 4 ~ 6 | 5 |
| NRF152 | 152 | 4 ~ 6 | 5 |
| NRF203 | 203 | 4 ~ 6 | 5 |
| NRF254 | 254 | 4 ~ 6 | 5 |
| NRF304 | 304 | 4 ~ 6 | 5 |
| NRF355 | 355 | 4 ~ 6 | 5 |
| NRF406 | 406 | 4 ~ 6 | 5 |
| NRF457 | 457 | 4 ~ 6 | 5 |
| NRF508 | 508 | 4 ~ 6 | 5 |
| NRF600 | 600 | 4 ~ 6 | 5 |
Note: Specifications, colors, inner rubber thickness, etc. can be customized according to requirements.
